Our fully automatic paper straw making machine is customizable for different straw diameters, including 4mm, 6mm, 8mm, 10mm, 12mm, 14mm and other custom sizes. It adopts multi-layer paper winding technology with servo synchronous cutting system, which ensures smooth straw surface, uniform wall thickness and precise cutting length without burrs.
This paper straw production line integrates paper unwinding, gluing, winding, fixed-length cutting and finished product collection into one unit, with stable operation, low failure rate and high production efficiency. The machine supports food-grade paper raw materials, producing eco-friendly biodegradable paper drinking straws to replace plastic straws, meeting global food safety and environmental protection standards.
Disposable straight paper straws for beverage shops, coffee shops, milk tea stores, restaurants
Thickened paper straws for bubble tea, milkshake, fruit smoothies
Mini thin paper straws for juice, yogurt, cocktail, drinking water
Custom printed paper straws with brand logos for catering packaging brands
Parameter | Details |
|---|---|
Production Speed | 90-100m/min (related to straw size and material quality) |
Applicable Material | Food-grade kraft paper |
Power Supply | 380V/50Hz (customizable ) |
Total Power | 10.0kW |
Machine Dimension | 4500×800×1500mm (L×W×H) |
Net Weight | 2500kg |
Straw Diameter Range | 4.2-13mm (customizable) |
Straw Length Range | 100-250mm (adjustable via control panel, customizable up to 300mm) |
Control System | PLC touch screen |
Safety & Certification | CE |
Engineered to maximize operational efficiency, this machine integrates cutting-edge technology with robust mechanical design. Every feature is meticulously crafted to reduce manual intervention while elevating the quality of the final product.
The heart of the machine is its responsive PLC touch screen interface. This highly intuitive control center allows operators to manage the entire lifecycle of the straw creation process with a few simple taps. By automating paper unwinding, precise glue application, forming, and counting, the system drastically reduces reliance on highly skilled labor while nearly eliminating human error.
Crisp, high-contrast visual interface for real-time monitoring of production metrics.
Seamless parameter adjustments, allowing quick transitions between different straw specifications.
Automated counting and batching to streamline downstream packaging processes.
Navigating international regulatory landscapes is effortless with equipment designed around uncompromising safety standards. Every surface that contacts the raw materials is manufactured from certified food-grade stainless steel and specialized alloys, ensuring zero contamination.
Perfectly handles 30-80gsm food-grade kraft and coated papers without tearing or jamming.
Fully compliant with FDA and EU 10/2011 standards, ensuring the end products are safe for all beverage and food applications.
CE and ISO certifications guarantee the machine meets the highest global manufacturing and safety benchmarks.
Modern production facilities demand equipment that balances high output with responsible energy consumption. This machine is a masterclass in efficient power utilization, drawing only 7.5kW during full operation.
Optimized electrical draw significantly lowers overhead costs compared to legacy models.
Constructed with a high-strength, anti-corrosive steel frame that absorbs operational vibrations.
Exceptional wear resistance ensures a prolonged operational lifespan, delivering an outstanding return on investment even in harsh industrial environments.
To meet the dynamic demands of the modern packaging sector, flexibility and speed must go hand in hand. This equipment is specifically calibrated to handle massive order volumes while maintaining the agility to pivot between diverse product configurations.
Time is the most critical asset on the factory floor. The core advantage of this system is its breathtaking speed, consistently churning out 100 meters of perfectly formed paper straws every sixty seconds. This velocity is sustained by a high-torque motor and a flawlessly synchronized paper feeding mechanism.
Maintains ±5% adjustable speed accuracy to match specific material tolerances.
Drastically reduces downtime with a continuous, jam-resistant feeding architecture.
Empowers large-scale facilities to meet tight delivery deadlines with absolute confidence.
Market trends shift rapidly, from ultra-slim stirrers for coffee shops to wide-diameter straws for bubble tea and milkshakes. This machine provides the mechanical flexibility to cater to every niche.
Standard production covers diameters from 5-12mm, with deep customization available for 3-15mm profiles.
Length adjustments from 100-250mm can be executed swiftly via the control panel, with structural support for lengths up to 300mm.
Razor-sharp multi-cut blade system ensures every straw is cleanly severed, leaving no frayed edges or paper dust.
Equipment downtime is the enemy of profitability. To combat this, the machine features a highly accessible modular design and intelligent software that anticipates issues before they cause a halt in production.
Quick-release mechanisms allow operators to swap out cutting blades and glue applicators in minutes.
Built-in self-diagnostic software continuously monitors motor temperatures, tension levels, and electrical currents.
Early warning alerts are displayed directly on the PLC screen, preventing catastrophic breakdowns and minimizing repair costs.
Investing in industrial machinery is a commitment to long-term operational success. We provide more than just equipment; we deliver a comprehensive ecosystem of support, engineering excellence, and industry expertise designed to elevate your manufacturing capabilities.
Unwavering Reliability: Our machines are rigorously tested under extreme stress conditions to ensure they perform flawlessly from the moment they are commissioned on your floor.
Deep Customization: We understand that no two facilities are identical. We offer tailored modifications, ranging from voltage adaptations (220V/380V) to the integration of automatic stacking and custom logo printing units.
End-to-End Lifecycle Support: From initial technical consultations to on-site installation and comprehensive operator training, our engineering team is with you at every step.
Responsive Aftercare: Enjoy peace of mind with a solid 1-year warranty on all core components, backed by round-the-clock technical support to ensure your lines never stop moving.
We understand that evaluating complex production equipment requires detailed technical insights. Below are answers to the most critical questions posed by engineering teams and facility operators.
The machine utilizes a highly synchronized servo-driven cutting system that tracks the speed of the extruded paper tube in real-time. This ensures the multi-knife cutting mechanism matches the exact velocity of the material, resulting in perfectly uniform lengths and clean, crush-free edges regardless of the operational speed.
Yes. The tension control system within the paper unwinding unit is highly sensitive and fully adjustable. Operators can easily calibrate the tension via the PLC interface to accommodate food-grade kraft and coated papers ranging from 30gsm to 80gsm, preventing web breaks on thinner papers and ensuring tight, secure winding on thicker stocks.
Changing the straw diameter requires swapping the central forming mandrel and adjusting the winding belts. Because of the machine's modular design, an experienced operator can complete this tooling changeover and recalibrate the system in a highly efficient timeframe, keeping production interruptions to an absolute minimum.
The PLC system is integrated with a network of sensors monitoring critical components such as motor load, heater temperatures, and paper tension. If any parameter drifts outside the optimal safety threshold, the system triggers an immediate visual and auditory alert, allowing operators to perform preventative maintenance before a mechanical failure occurs.
Absolutely. While the standard configuration operates on 380V/50Hz, the electrical architecture can be fully customized to 220V/60Hz or other regional specifications prior to shipping. Additionally, we can modify the orientation of the discharge conveyors and integrate automated collection systems to perfectly match your existing floor plan and downstream workflow.
