CFJB-50
Chuangfeng
| Quantity: | |
|---|---|
The CFJB-50 Paper Tube Curling And Grooving Machine represents a significant technological leap forward in paper core processing. When you observe this equipment in a live manufacturing environment, the rhythmic, precise sound of its pneumatic driving system reflects the meticulous engineering beneath its heavy-duty exterior. Crafted to transform raw paper tubes into flawlessly grooved and curled cores, it completely eliminates the jagged edges, tearing, and inconsistent depths that frequently plague manual or semi-automatic processing methods. The tactile finish of the processed POY and DTY tubes feels exceptionally smooth to the touch, ensuring that delicate textiles, fine threads, or industrial films wound around them remain pristine and entirely snag-free during downstream applications.
By integrating this sophisticated machinery into your facility, you are not merely upgrading a single step in your workflow; you are making a strategic investment to drastically reduce material waste and operator fatigue. The sleek, industrial-grade stainless steel chassis stands as a visual testament to its longevity, promising years of relentless, high-torque performance even in the most demanding, dust-heavy manufacturing environments. Every internal component is machined to exact tolerances, delivering a level of craftsmanship that translates directly into higher yield rates, lower maintenance overhead, and superior end-product quality that will consistently exceed the strict standards of your most demanding clients.
Parameter | Details |
|---|---|
Model Number | CFJB-50 |
Applicable Paper Tube Inner Diameter | 50-150mm |
Curling Thickness | 1-4mm |
Grooving Thickness | 4-15mm |
Tube Length | 50-350mm |
Production Speed | 20-30 pcs/min |
Tube Loading and Unloading | Automatically |
Driving Way | Pneumatic |
Tube Fixing Way | Pneumatic |
Operator Requirement | 1 person |
Working Air Pressure | 0.3-0.6Mpa |
Power Supply | 380V / 3 Phase / 50Hz |
Machine Measurement | 2000*1600*1200mm |
Machine Weight | 850kgs |
Molds Included | 1 set |
