The CFJG-SK-50 represents the pinnacle of modern paper tube manufacturing, seamlessly combining robust mechanical engineering with intelligent automation. When you observe this machine on the factory floor, the quiet, rhythmic hum of its highly efficient 5.5 kW motor and the smooth, vibration-free operation speak volumes about its superior build quality. Every structural component, from the heavy-duty steel chassis to the precision-machined winding rollers, is meticulously designed to deliver a flawless, perfectly smooth tactile finish on every single paper core produced. The integration of a specialized heating device ensures that the adhesives cure rapidly and evenly across all layers. This critical addition results in tubes that feel incredibly rigid to the touch and exhibit exceptional load-bearing strength, completely free from the moisture-induced warping or delamination often found in standard forming equipment.
Investing in this advanced forming system means fundamentally transforming your operational workflow. By eliminating the frustrating bottlenecks associated with manual adjustments and frequent mechanical downtime, your facility can achieve a seamless, continuous output of perfectly cylindrical paper tubes. The meticulously engineered transmission system minimizes energy dissipation, translating to significantly lower operational costs while maintaining peak performance during demanding, round-the-clock shifts. Whether your facility is churning out delicate, pristine cosmetic packaging cores or heavy-duty, high-tension textile winding tubes, this machinery adapts effortlessly. It ensures that your final product consistently meets the stringent quality tolerances and aesthetic standards expected by the most discerning global clients.
Review the comprehensive technical parameters of the CFJG-SK-50 model below. These specifications represent the standard configuration, engineered to deliver optimal performance, structural stability, and energy efficiency across various demanding industrial applications.
Model | CFJG-SK-50 |
Production Speed | 1-20 m/min (Up to 150 pcs/min) |
Applicable Paper Tube Diameter | 20 - 100 mm (Customizable 5 - 200 mm) |
Paper Tube Length | 500 - 5000 mm |
Thickness | 1 - 5 mm |
Motor Power | 5.5 kW |
Voltage | 380V / 3phase / 50Hz (Customizable) |
Control System | High Precision Servo Control System / PLC |
Gumming Type | Double Side |
Machine Weight | 1500 kgs |
Dimensions (L*W*H) | 2700 1600 1900 mm |
Certification | CE |
Warranty | 1.5 Years |
Designed to solve the most pressing challenges in modern manufacturing facilities, this equipment goes beyond basic functionality to deliver a truly optimized production experience. Every feature is crafted to reduce material waste, lower labor costs, and maximize your operational uptime.
Achieve unparalleled precision with the integrated High Precision Servo Control System and advanced PLC programming. This powerful combination dynamically adjusts operational tension and speed in real-time.
Maintains strict dimensional consistency across massive, high-volume production runs.
Ensures razor-smooth cutting edges, entirely eliminating the need for secondary trimming processes.
Dramatically reduces material waste, keeping product defect rates strictly below the 1% threshold.
Speed without compromising structural quality is the hallmark of this system. The optimized mechanical architecture allows for rapid, continuous output to meet tight delivery schedules.
Reaches impressive production speeds ranging from 1 to 20 meters per minute.
Capable of producing up to 150 individual pieces per minute, depending on the specified tube dimensions.
Advanced transmission mechanics significantly lower energy consumption during extended operational shifts.
Complex industrial machinery should not require a steep learning curve. The user-centric design philosophy empowers operators of all skill levels to manage the line effectively.
Responsive touch-screen panel for the effortless input of cutting length, running speed, and batch quantities.
Built-in automated fault diagnosis instantly pinpoints and visualizes potential mechanical or electrical issues on the display.
Reduces your facility's reliance on specialized technicians, drastically lowering overall maintenance and training expenditures.
We recognize that no two production lines are exactly alike. This machinery platform is built with extraordinary architectural flexibility, allowing it to be tailored precisely to your unique market demands and facility constraints.
Whether you are crafting delicate, thin-walled cores or robust industrial cylinders, the machine adjusts seamlessly to your exact specifications.
The standard operational range effortlessly covers tube diameters from 20 mm to 100 mm and wall thicknesses of 1 mm to 5 mm.
Deep customization services are available to expand diameter capabilities from a narrow 5 mm up to a massive 200 mm.
Seamlessly handles extended tube lengths ranging from 500 mm to 5000 mm, accommodating highly diverse industry requirements.
Elevate your product offering by integrating specialized functional modules directly into the primary forming line.
Double-side gumming capabilities ensure superior layer adhesion, drastically improving the core's crush resistance.
Optional integration for inline automatic labeling and precision printing to streamline your downstream finishing processes.
Customizable voltage settings and adaptable core components to perfectly match your regional electrical grids and operational preferences.
This equipment is engineered from the ground up to serve as the reliable backbone for a wide array of specialized manufacturing sectors.
Premium Packaging: Create pristine, odor-free tubes for high-end cosmetics, food safety applications, and pharmaceuticals.
Textile & Apparel: Manufacture perfectly balanced cores for the high-speed winding of delicate yarns, threads, and heavy fabrics without snagging.
Printing & Media: Produce high-strength cores capable of withstanding extreme web tension for film, labels, and commercial paper rolls.
Construction & Infrastructure: Form heavy-duty, environmentally friendly paper tubes utilized in modern concrete pouring applications.
Household Goods: Meet the massive volume demands of the daily necessities market, including toilet tissue and paper towel roll production.
Procuring heavy industrial machinery is a significant investment that requires a trustworthy, proven partner. We deliver not just a machine, but a comprehensive ecosystem of reliability, certified quality, and unwavering post-installation support to ensure your long-term operational success.
Our manufacturing philosophy centers entirely on equipment longevity and relentless performance in the harshest factory environments.
Constructed from premium-grade steel and highly wear-resistant moving components, bringing the total machine weight to a highly stable 1500 kgs.
Subjected to rigorous, multi-stage quality control testing before ever leaving our manufacturing facility.
Fully compliant with strict CE international certification standards, guaranteeing operational safety and mechanical excellence.
Backed by a solid 1.5-year warranty on all core components, providing your procurement team with true peace of mind.
Downtime is the absolute enemy of profitability. Our global support infrastructure is meticulously designed to keep your operations moving flawlessly.
End-to-end technical assistance, encompassing on-site installation guidance, precision commissioning, and thorough operator training.
Access to a dedicated 24/7 online technical support team ready to resolve complex operational queries instantly.
Guaranteed inventory of authentic spare parts, ensuring rapid dispatch and delivery within 3 to 7 working days to minimize production interruptions.
To assist your team in making a highly informed decision, we have compiled detailed answers to the most common technical inquiries regarding our servo-controlled paper tube forming equipment.
The standard CFJG-SK-50 model is meticulously engineered to process paper tube wall thicknesses ranging from 1 mm up to 5 mm. This specific range provides the ideal balance of structural rigidity and material efficiency for most packaging, textile, and printing applications. The advanced double-side gumming system ensures that even at the maximum 5 mm thickness, the paper layers remain tightly bonded without any risk of delamination.
Absolutely. While the default configuration operates on a standard 380V / 3-phase / 50Hz power supply, our engineering team can fully customize the motor and internal electrical components. This ensures the machinery will seamlessly integrate with your facility's specific regional voltage and frequency standards, guaranteeing safe and optimal performance immediately upon installation.
The integrated heating device significantly accelerates the curing process of the adhesive during the high-speed spiral winding phase. This rapid curing locks the paper layers together instantly, drastically increasing the crush strength and overall dimensional stability of the tube. It also prevents unwanted moisture retention, resulting in a product that feels exceptionally solid and is ready for immediate downstream processing or shipping.
We maintain a robust and continuous inventory of all critical wear components and genuine spare parts at our primary facility. In the event that a replacement is required, our streamlined global logistics network allows us to process, dispatch, and deliver parts within a rapid window of 3 to 7 working days, drastically minimizing any potential production downtime for your facility.
No, it does not. We have designed the control interface specifically to reduce your reliance on highly specialized, expensive labor. The intuitive PLC touch-screen allows standard operators to easily input and adjust all critical production variables with minimal training. Furthermore, the built-in automatic fault diagnosis system visually identifies any operational anomalies on the screen, making routine troubleshooting and basic maintenance highly straightforward.
